10.1" Face Fingerprint RFID Card Access Control Time Attendance Terminal

Payment Terms : T/T

Operating System : Optional RK 3568/3288, Quad-core CPU, 2.0/1.8 GHz, Android 11/7.1 versions

Color : Black

POE/RS485 : Optional

Configuration : 2GB RAM + 16GB Storage

Installation Method : Wall-mounted

Screen Brightness : 300 cd/m²

Operating Parameters : Voltage: 12V Current: 3A Operating Temperature: -10°C to 60°C Humidity: 5% to 90% RH

Place of Origin : China

Model Number : 010

Packaging Details : 8 inches

Supply Ability : 100+pcs+day

MOQ : Negotiable

Price : Negotiable

Viewing Angle : 178° full-view angle (R/L)

Three-Color Breathing Light : Red, Green, Blue (optional)

Body Craftsmanship : CNC precision-machined aluminum alloy with anodized finish

Monocular Camera : 2MP HD monocular camera, recognition distance: 0.4-2m (optional)

Speaker : 3W

Surface Material : Tempered glass front cover

Touch Screen : 10-point capacitive touch

WiFi : Supported

LCD Screen Size : 8 inches

Screen Resolution : 800 × 1280

Interfaces : Phoenix Terminal Integrated Interface (7 PIN): NO (Relay Normally Open) COM (Relay Common Terminal) NC (Relay Normally Closed) B (RS485 Signal Wire B) A (RS485 Signal Wire A) GND (Ground) 12V (12V Power Supply Positive Terminal) Type-C (5V) Type-A (OTG)
